Technical Data

O.D of the Tube or Pipe Standard Fins Per Inch CRIMPED TYPE IL TYPE G TYPE Integral or Low Finned Tubes
Material : Copper,Alu.,CRCA (m.s), cupronickle, Brass, Etc Material : M.S CRCA & Copper Aluminium S.S. Copper & M.S.CACA MK Of tube Standard
inch mm std.fin ht std thk std.fin ht std thk std.fin ht std thk std.fin ht std thk std.fin ht std thk FM inch FM inch
5/8" 15.88mm 8 10mm 0.4mm - - - - - - - - 19 FPI 26 FPI 19 FPI 26 FPI
3/4" 19.05 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 9 mm 0.5 mm 12 mm 0.45 mm 19 FPI 26 FPI 19 FPI 26 FPI
7/8" 22.23 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 12 mm 0.5 mm 12 mm 0.45 mm 19 FPI 26 FPI 19 FPI 26 FPI
1" 25.4 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 12 mm 0.5 mm 12 mm 0.45 mm 19 FPI 26 FPI 19 FPI 26 FPI
1" NB 33.4 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 12 mm 0.5 mm 12 mm 0.45 mm - - - -
2" NB 50.8 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 12 mm 0.5 mm 12 mm 0.45 mm - - - -
3" NB 76.2 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 12 mm 0.5 mm 12 mm 0.45 mm - - - -
4" NB 76.2 mm 8 10 mm 0.4 mm 15.5 mm 0.45 mm 12 mm 0.6 mm 12 mm 0.5 mm 12 mm 0.45 mm - - - -
Tube material : Carbon Steel, Stainless Steel, Aluminium, Copper, Brass, Cupronickle
Tube diameter : 5/8" 0.D to 4" 0.D length upto 40 feet long
Fin height : Minimum 2mm to 40mm
Fin thickness : 0.2 mm to 2.5mm
No. of fin/in : 2 to 12 FPI
Fin material : CRCA, Stainless Steel, Aluminium, Copper, Brass, Cupronickle
Integral/Low Fin : 5/8" 0.D to 1" 0.D tube length upto 30 feet long
Thickness of tube : 14 SWG/BWG to 20 SWG/BWG
Material : Carbon Steel, Stainless Steel, Aluminium, Copper, Brass, Cupronickle
Number of Fin/Inch : 11 FPI, 19 FPI, 26 FPI
